Re: Liquid Synergy Designs Inc. -ASIC mining hardware
by
jesse11
on 08/11/2013, 18:09:56 UTC
Does anyone have K16's running with a killawatt meeter? Pics or it didn't happen! We are looking for Mhz you are running the K16s at + GHs + watts at the wall (from the killawatt meeter).

If you are chaining K16(s) off your computer PSU(power supply unit), then just take a reading with/without the K16(s) running (unplugged preferably) - this should get us in the ball park. Yes I know cgminer will load up the computer CPU resulting in more wattage draw, but it shouldn't be by much.



Just in case: https://www.google.com/#q=killawatt



Here ya go guys, I have a certified digital elect. usage monitor I use on my rigs when benchmarking for world records. As you can see I hooked it up to my old server (Q9550) and it showing 474-472 watts, two 7790's, 6 BE's and 3 K16's @ 360MHz Grin




Unplugged the PCI-E connects (running from a corsair 1000 watt PSU) to shut down the K16's and now we have 292-290 watts.




Results:
474 - 292 = 182 / 3 = 60.666667watts

Each K16 uses 60watts  Grin  Happy Mining  Smiley   Jesse11
