Re: CGMINER ASIC miner monitoring RPC linux/win/osx/mips/arm/r-pi 4.1.0
hi,
how can i update the cgminer version from a antminer s1? Normally the software is deployed with a new firmware.
thanks
Yeah I can build binaries and ipk files now.how can i update the cgminer version from a antminer s1? Normally the software is deployed with a new firmware.
thanks
I'm not 100% sure of building a complete firmware file, that will come a little later.
The luci web code that displays the stats doesn't work with the correct API code, so I'll see if I can sort that out today and hack a binary that works with both the luci code and of course includes the correct API output for anyone who accesses it.
hi,
thats sounds good
Re: CGMINER ASIC miner monitoring RPC linux/win/osx/mips/arm/r-pi 4.1.0
hi,
how can i update the cgminer version from a antminer s1? Normally the software is deployed with a new firmware.
thanks
how can i update the cgminer version from a antminer s1? Normally the software is deployed with a new firmware.
thanks
hi,
any feedback?
Hi,
a short question.
if i take a look at the network configuration i find to physical interfaces (eth0 (default dhcp) and eth1 with the static default ip). I know that the antminer did only have one plugin option for one cable but what is with eth0? is there a hidden 2nd option?
thanks
a short question.
if i take a look at the network configuration i find to physical interfaces (eth0 (default dhcp) and eth1 with the static default ip). I know that the antminer did only have one plugin option for one cable but what is with eth0? is there a hidden 2nd option?
thanks
Hi,
i need to setup my antminer s1 behind a http proxy.
did anybody know how to do the setup?
i need to setup my antminer s1 behind a http proxy.
did anybody know how to do the setup?
any idea?
Re: CGMINER ASIC miner monitoring RPC linux/win/osx/mips/arm/r-pi 4.0.1
hi,
is there an option to use a http proxy on multi pools?
i found this but it is only for single pools:
is there an option to use a http proxy on multi pools?
i found this but it is only for single pools:
Code:
EXECUTIVE SUMMARY ON USAGE:
Single pool:
cgminer -o http://pool:port -u username -p password
Multiple pools:
cgminer -o http://pool1:port -u pool1username -p pool1password -o http://pool2:port -u pool2usernmae -p pool2password
Single pool with a standard http proxy:
cgminer -o "http:proxy:port|http://pool:port" -u username -p password
Single pool with a socks5 proxy:
cgminer -o "socks5:proxy:port|http://pool:port" -u username -p password
Single pool with stratum protocol support:
cgminer -o stratum+tcp://pool:port -u username -p password
The list of proxy types are:
http: standard http 1.1 proxy
http0: http 1.0 proxy
socks4: socks4 proxy
socks5: socks5 proxy
socks4a: socks4a proxy
socks5h: socks5 proxy using a hostname
Single pool:
cgminer -o http://pool:port -u username -p password
Multiple pools:
cgminer -o http://pool1:port -u pool1username -p pool1password -o http://pool2:port -u pool2usernmae -p pool2password
Single pool with a standard http proxy:
cgminer -o "http:proxy:port|http://pool:port" -u username -p password
Single pool with a socks5 proxy:
cgminer -o "socks5:proxy:port|http://pool:port" -u username -p password
Single pool with stratum protocol support:
cgminer -o stratum+tcp://pool:port -u username -p password
The list of proxy types are:
http: standard http 1.1 proxy
http0: http 1.0 proxy
socks4: socks4 proxy
socks5: socks5 proxy
socks4a: socks4a proxy
socks5h: socks5 proxy using a hostname
Guys, I have a strange Problem. Hope someone is able to help me. 0.05BTC bounty for getting my miners to atleast 2,6 Ghash each
I got 16 Antminer U1. All are running at 1,088 V. I have a 49 Port USB Hub and a 450W PSU exclusively for those 16 U1. I have additional coolers attached and a fan blowing cool air. The Miners get definitely not too warm.
I tried Bitmain´s Cgminer, different BFGminer version on Windows, Minepeon and Raspcontrol. Cgminer gave me too much errors and for BFGminer I have the following Problem:
While I should be able to get 48 or atleast 44,8 Ghash out of the 16 U1, I get far less. Recently did some testing with BFGminer 3.10 and Raspcontrol
At 4D81 I get 6 Ghash
At 4C81 I get 10 Ghash
At 0B81 I get 12 Ghash
At 0A81 I get 15 Ghash
At 0981 I get 14 Ghash
At 0781 I get 10 Ghash
The Problem here is, that most Miners run somewhere under 500 Mhash. No Hardware Errors. Those U1 who do more Ghash are getting warmer then those who only do some Mhash. From test to test the variance is very big.
Currently they run with 4C81 under BFGminer 3.9.0 and Minepeon with 25Ghash. For some reason the hashrates with bfgminer 3.9.0 are similar among all sticks. The best result I got so far was about 30Ghash (also BFGminer 3.9.0 and Minepeon). The funny thing is, that I didn't give any frequenzy to BFGminer in this test so that the Miner should have run with 1,6Ghash. For some reasen they did nearly 2Ghash. This was absolut stable (ran for <24 hours). Again: I do not get any errors (or very very few on some sticks <.1) beyond 4E81.
Sorry for the bad english
Thanks
Muto
I got 16 Antminer U1. All are running at 1,088 V. I have a 49 Port USB Hub and a 450W PSU exclusively for those 16 U1. I have additional coolers attached and a fan blowing cool air. The Miners get definitely not too warm.
I tried Bitmain´s Cgminer, different BFGminer version on Windows, Minepeon and Raspcontrol. Cgminer gave me too much errors and for BFGminer I have the following Problem:
While I should be able to get 48 or atleast 44,8 Ghash out of the 16 U1, I get far less. Recently did some testing with BFGminer 3.10 and Raspcontrol
At 4D81 I get 6 Ghash
At 4C81 I get 10 Ghash
At 0B81 I get 12 Ghash
At 0A81 I get 15 Ghash
At 0981 I get 14 Ghash
At 0781 I get 10 Ghash
The Problem here is, that most Miners run somewhere under 500 Mhash. No Hardware Errors. Those U1 who do more Ghash are getting warmer then those who only do some Mhash. From test to test the variance is very big.
Currently they run with 4C81 under BFGminer 3.9.0 and Minepeon with 25Ghash. For some reason the hashrates with bfgminer 3.9.0 are similar among all sticks. The best result I got so far was about 30Ghash (also BFGminer 3.9.0 and Minepeon). The funny thing is, that I didn't give any frequenzy to BFGminer in this test so that the Miner should have run with 1,6Ghash. For some reasen they did nearly 2Ghash. This was absolut stable (ran for <24 hours). Again: I do not get any errors (or very very few on some sticks <.1) beyond 4E81.
Sorry for the bad english
Thanks
Muto
Hi,
take a look at my solution:
https://bitcointalk.org/index.php?topic=390929.msg5155376#msg5155376
i needed the y usb adapter without my antminer run slow as yours.
hi guys , I've tried to mod R1 and R2 to the value of 10k and 4.99k according to the instruction for ocing, but unsuccessfull. My 2 ants oced at 2gh to start out with but then they start to droped after 5 minutes of start up to the lower hashing rate, less than 1 gh. I did have a fan on them with no heatsink though, the ants were really hot. Without success so I decided to change R1 and R2 back to the way they were, but now my hashing rate stay about 1.54gh and 1.58gh at oc 0981. What have I done wrong here, thanks for your help in advance.
Hi,
less power?
i power my modded antminer with a y usb cable on a usb 3 hub.
Hallo Zusammen,
bei Interesse verkaufe ich meine beiden 18 GHS Antminer Blöcke.
Sie bestehen je aus:
1x Massiven Aluminium Kühlkörper
6x Antminer U1 die jeweils auf 1,1V über R1 und R2 eingestellt wurden
je 2 kleine Kühlkörper auf der Ameise
Alle sechs Ameisen wurden direct mit Wärmeleitpaste auf den Kühlkörper geschraubt.
Bei mir laufen sie wie folgt:
bei Interesse verkaufe ich meine beiden 18 GHS Antminer Blöcke.
Sie bestehen je aus:
1x Massiven Aluminium Kühlkörper
6x Antminer U1 die jeweils auf 1,1V über R1 und R2 eingestellt wurden
je 2 kleine Kühlkörper auf der Ameise
Alle sechs Ameisen wurden direct mit Wärmeleitpaste auf den Kühlkörper geschraubt.
Bei mir laufen sie wie folgt:
Code:
bfgminer/bfgminer -S antminer:all --set-device antminer:clock=x4E81
Code:
bfgminer version 3.10.0 - Started: [2014-02-15 22:13:11] - [ 0 days 11:39:17]
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.bitcoin.cz diff 34 with stratum as user xyz
Block: ...40e5f335 #286152 Diff:2.62G (18.77Ph/s) Started: [09:47:44]
ST:25 F:1 NB:108 AS:1 BW:[107/ 57 B/s] E:99.08 I: 275uBTC/hr BS:485k
12 | 29.39/29.41/34.83Gh/s | A:15642 R:75+66(.78%) HW:9/.00%
------------------------------------------------------------------------------------------------------------------
AMU 0: | 2.45/ 2.45/ 2.90Gh/s | A: 1382 R: 7+12(1.1%) HW:0/none
AMU 1: | 2.48/ 2.45/ 2.91Gh/s | A: 1284 R:13+ 6(1.3%) HW:0/none
AMU 2: | 2.47/ 2.45/ 2.89Gh/s | A: 1334 R: 7+ 3(.72%) HW:2/.01%
AMU 3: | 2.45/ 2.45/ 2.91Gh/s | A: 1261 R: 2+11(.76%) HW:1/.00%
AMU 4: | 2.45/ 2.45/ 2.92Gh/s | A: 1310 R: 6+ 6(.91%) HW:1/.00%
AMU 5: | 2.44/ 2.45/ 2.88Gh/s | A: 1258 R: 7+ 7(.94%) HW:1/.00%
AMU 6: | 2.53/ 2.45/ 2.89Gh/s | A: 1301 R: 6+ 2(.51%) HW:0/none
AMU 7: | 2.40/ 2.45/ 2.90Gh/s | A: 1346 R: 6+ 4(.60%) HW:0/none
AMU 8: | 2.43/ 2.45/ 2.93Gh/s | A: 1314 R: 5+ 5(.56%) HW:1/.00%
AMU 9: | 2.48/ 2.45/ 2.92Gh/s | A: 1275 R: 7+ 2(.69%) HW:1/.00%
AMU10: | 2.40/ 2.45/ 2.89Gh/s | A: 1260 R: 3+ 4(.47%) HW:1/.00%
AMU11: | 2.48/ 2.45/ 2.90Gh/s | A: 1320 R: 6+ 4(.72%) HW:1/.00%
------------------------------------------------------------------------------------------------------------------
[2014-02-16 09:51:34] Accepted 05a5585e AMU10 pool 2 Diff 45/34
[2014-02-16 09:51:34] Accepted 01086650 AMU 3 pool 2 Diff 246/34
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.bitcoin.cz diff 34 with stratum as user xyz
Block: ...40e5f335 #286152 Diff:2.62G (18.77Ph/s) Started: [09:47:44]
ST:25 F:1 NB:108 AS:1 BW:[107/ 57 B/s] E:99.08 I: 275uBTC/hr BS:485k
12 | 29.39/29.41/34.83Gh/s | A:15642 R:75+66(.78%) HW:9/.00%
------------------------------------------------------------------------------------------------------------------
AMU 0: | 2.45/ 2.45/ 2.90Gh/s | A: 1382 R: 7+12(1.1%) HW:0/none
AMU 1: | 2.48/ 2.45/ 2.91Gh/s | A: 1284 R:13+ 6(1.3%) HW:0/none
AMU 2: | 2.47/ 2.45/ 2.89Gh/s | A: 1334 R: 7+ 3(.72%) HW:2/.01%
AMU 3: | 2.45/ 2.45/ 2.91Gh/s | A: 1261 R: 2+11(.76%) HW:1/.00%
AMU 4: | 2.45/ 2.45/ 2.92Gh/s | A: 1310 R: 6+ 6(.91%) HW:1/.00%
AMU 5: | 2.44/ 2.45/ 2.88Gh/s | A: 1258 R: 7+ 7(.94%) HW:1/.00%
AMU 6: | 2.53/ 2.45/ 2.89Gh/s | A: 1301 R: 6+ 2(.51%) HW:0/none
AMU 7: | 2.40/ 2.45/ 2.90Gh/s | A: 1346 R: 6+ 4(.60%) HW:0/none
AMU 8: | 2.43/ 2.45/ 2.93Gh/s | A: 1314 R: 5+ 5(.56%) HW:1/.00%
AMU 9: | 2.48/ 2.45/ 2.92Gh/s | A: 1275 R: 7+ 2(.69%) HW:1/.00%
AMU10: | 2.40/ 2.45/ 2.89Gh/s | A: 1260 R: 3+ 4(.47%) HW:1/.00%
AMU11: | 2.48/ 2.45/ 2.90Gh/s | A: 1320 R: 6+ 4(.72%) HW:1/.00%
------------------------------------------------------------------------------------------------------------------
[2014-02-16 09:51:34] Accepted 05a5585e AMU10 pool 2 Diff 45/34
[2014-02-16 09:51:34] Accepted 01086650 AMU 3 pool 2 Diff 246/34
i do have an old thermaltake water cooling kit with 1 cpu and 2 gpu blocks. i think im gonna donate 1 of my 7 miners to the cause and see what i can pull on air then water.
same situation for me, I have a wb for cpu, one for gpu and one for chipset, all unused... And I have a 35w peltier cell as well, nice for some test :p but I'm pretty sure, with this configuration an U1 lasts little... so it coulb be for testing purpose, not for daily mining.
Let us know about the tests!
this is really nice, but are you planning to leave this for daily use? what is the expected duration of the ants @1.1v 3gh/s?
Hi,
my plan was to build it.
i like to build thinks and if anybody is intrested in it a can sell it too.
Re: BFGMiner 3.10.0: modular ASIC+FPGA, GBT+Strtm, RPC, Mac/Lnx/W64, AntU1, DRB, HFA
@deagel
Love the photo of your ANTminer rig.
Looks like you've removed the aluminum heat sink that comes with each ANTminer and have attached (screwed?) each ANTminer to your massive heat sink block (6 ANTminers per block). Did you have to drill pilot holes in the big heat sink block? Did you use metal or plastic/nylon screws to attach the ANTminer to the block? Or did you just use thermal paste to 'glue' the ANTminer to the block?
Love the photo of your ANTminer rig.
Looks like you've removed the aluminum heat sink that comes with each ANTminer and have attached (screwed?) each ANTminer to your massive heat sink block (6 ANTminers per block). Did you have to drill pilot holes in the big heat sink block? Did you use metal or plastic/nylon screws to attach the ANTminer to the block? Or did you just use thermal paste to 'glue' the ANTminer to the block?
https://bitcointalk.org/index.php?topic=390929.msg5155376#msg5155376
My way to 12 x ~3ghs with antminer u1
Hi ther i like to show you my way to get 3ghs per antminer.
Setup:
Intel Atom mini PC
- OS Ubuntu Server (latest version)
- 3 x USB3 Hub
- 12 x Antminer with 1.1V on R1 and R2
- 12 x 0,5m USB Kabel
- 12 x USB y power Adapter Kabel
I removed the aluminum heat sink that comes with each ANTminer and have attached (screwed) each ANTminer to my massive heat sink block (6 ANTminers per block).
I have to drill pilot holes in the big heat sink block and useed metal screws (the one that cames with the antminer) to attach the ANTminer to the block.
Hi ther i like to show you my way to get 3ghs per antminer.
Setup:
Intel Atom mini PC
- OS Ubuntu Server (latest version)
- 3 x USB3 Hub
- 12 x Antminer with 1.1V on R1 and R2
- 12 x 0,5m USB Kabel
- 12 x USB y power Adapter Kabel
I removed the aluminum heat sink that comes with each ANTminer and have attached (screwed) each ANTminer to my massive heat sink block (6 ANTminers per block).
I have to drill pilot holes in the big heat sink block and useed metal screws (the one that cames with the antminer) to attach the ANTminer to the block.
Code:
bfgminer version 3.10.0 - Started: [2014-02-14 19:05:24] - [ 0 days 13:46:22]
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.mining.eligius.st diff 16 with stratum as user 17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ
Block: ...295b4242 #285937 Diff:2.62G (18.77Ph/s) Started: [08:50:44]
ST:23 F:36 NB:96 AS:0 BW:[ 8/ 6kB/s] E:1.08 I: 278uBTC/hr BS:5.94M
12 | 28.07/29.13/34.49Gh/s | A:282660 R:111+4(.33%) HW:204/.05%
-------------------------------------------------------------------------------------------------------------
AMU 0: | 2.44/ 2.43/ 2.90Gh/s | A: 23643 R: 11+0(.43%) HW: 21/.06%
AMU 1: | 2.43/ 2.43/ 2.90Gh/s | A: 23764 R: 8+0(.16%) HW: 14/.04%
AMU 2: | 2.30/ 2.43/ 2.86Gh/s | A: 23534 R: 13+1(.55%) HW: 18/.05%
AMU 3: | 2.39/ 2.42/ 2.85Gh/s | A: 23233 R: 11+0(.23%) HW: 14/.04%
AMU 4: | 2.44/ 2.43/ 2.87Gh/s | A: 23554 R: 11+1(.58%) HW: 14/.04%
AMU 5: | 2.41/ 2.42/ 2.84Gh/s | A: 23290 R: 7+1(.26%) HW: 13/.04%
AMU 6: | 2.39/ 2.43/ 2.87Gh/s | A: 23548 R: 7+0(.02%) HW: 16/.05%
AMU 7: | 2.42/ 2.42/ 2.85Gh/s | A: 23320 R: 7+0(.30%) HW: 23/.07%
AMU 8: | 2.47/ 2.43/ 2.89Gh/s | A: 23755 R: 6+0(.29%) HW: 17/.05%
AMU 9: | 2.41/ 2.43/ 2.89Gh/s | A: 23682 R: 7+0(.24%) HW: 16/.05%
AMU10: | 2.41/ 2.43/ 2.89Gh/s | A: 23611 R: 9+0(.40%) HW: 20/.06%
AMU11: | 2.36/ 2.43/ 2.87Gh/s | A: 23731 R: 14+1(.45%) HW: 18/.05%
-------------------------------------------------------------------------------------------------------------
[2014-02-15 08:51:22] Accepted 0ba45666 AMU 7 pool 0 Diff 21/16
[2014-02-15 08:51:23] Accepted 0c5e28c5 AMU10 pool 0 Diff 20/16
[2014-02-15 08:51:29] Accepted 0f945b47 AMU11 pool 0 Diff 16/16
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.mining.eligius.st diff 16 with stratum as user 17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ
Block: ...295b4242 #285937 Diff:2.62G (18.77Ph/s) Started: [08:50:44]
ST:23 F:36 NB:96 AS:0 BW:[ 8/ 6kB/s] E:1.08 I: 278uBTC/hr BS:5.94M
12 | 28.07/29.13/34.49Gh/s | A:282660 R:111+4(.33%) HW:204/.05%
-------------------------------------------------------------------------------------------------------------
AMU 0: | 2.44/ 2.43/ 2.90Gh/s | A: 23643 R: 11+0(.43%) HW: 21/.06%
AMU 1: | 2.43/ 2.43/ 2.90Gh/s | A: 23764 R: 8+0(.16%) HW: 14/.04%
AMU 2: | 2.30/ 2.43/ 2.86Gh/s | A: 23534 R: 13+1(.55%) HW: 18/.05%
AMU 3: | 2.39/ 2.42/ 2.85Gh/s | A: 23233 R: 11+0(.23%) HW: 14/.04%
AMU 4: | 2.44/ 2.43/ 2.87Gh/s | A: 23554 R: 11+1(.58%) HW: 14/.04%
AMU 5: | 2.41/ 2.42/ 2.84Gh/s | A: 23290 R: 7+1(.26%) HW: 13/.04%
AMU 6: | 2.39/ 2.43/ 2.87Gh/s | A: 23548 R: 7+0(.02%) HW: 16/.05%
AMU 7: | 2.42/ 2.42/ 2.85Gh/s | A: 23320 R: 7+0(.30%) HW: 23/.07%
AMU 8: | 2.47/ 2.43/ 2.89Gh/s | A: 23755 R: 6+0(.29%) HW: 17/.05%
AMU 9: | 2.41/ 2.43/ 2.89Gh/s | A: 23682 R: 7+0(.24%) HW: 16/.05%
AMU10: | 2.41/ 2.43/ 2.89Gh/s | A: 23611 R: 9+0(.40%) HW: 20/.06%
AMU11: | 2.36/ 2.43/ 2.87Gh/s | A: 23731 R: 14+1(.45%) HW: 18/.05%
-------------------------------------------------------------------------------------------------------------
[2014-02-15 08:51:22] Accepted 0ba45666 AMU 7 pool 0 Diff 21/16
[2014-02-15 08:51:23] Accepted 0c5e28c5 AMU10 pool 0 Diff 20/16
[2014-02-15 08:51:29] Accepted 0f945b47 AMU11 pool 0 Diff 16/16
Hallo Zusammen,
bei mir laufen aktuell 9 von 12 ANT U1 miner mit stabilen 3ghs (2.9ghs), warum 9 naja mir fehlt noch ein hub.
Setup:
Intel Atom mini PC
- OS Ubuntu Server
- 3 x USB3 Hub
- 12 x Antminer die auf 1.1V eingestellt wurden
- 12 x 0,5m USB Kabel
- 12 x USB y power Adapter Kabel
WICHTIG
sehr gute Kühlung
ich habe 2 große Aluminium Kühlkörper genommen und die Ameisen dort direkt daraufgeschraubt und auch jeweils zwei kleine Kühlkörper auf die Oberseite der Ameise geklebt.
bei mir laufen aktuell 9 von 12 ANT U1 miner mit stabilen 3ghs (2.9ghs), warum 9 naja mir fehlt noch ein hub.
Setup:
Intel Atom mini PC
- OS Ubuntu Server
- 3 x USB3 Hub
- 12 x Antminer die auf 1.1V eingestellt wurden
- 12 x 0,5m USB Kabel
- 12 x USB y power Adapter Kabel
WICHTIG
sehr gute Kühlung
ich habe 2 große Aluminium Kühlkörper genommen und die Ameisen dort direkt daraufgeschraubt und auch jeweils zwei kleine Kühlkörper auf die Oberseite der Ameise geklebt.
Kannst du mal deine Startuparameter psoten? Welches Betriebssystem? Bei mir laufen die leider nur mit 2Ghash (obwohl @ 1,088V).
- Ubuntu Server minimal
- /bfgminer -S antminer:all --set-device antminer:clock=x4E81 -S all
Code:
bfgminer.conf
{
"pools" : [
{
"url" : "stratum+tcp://stratum.mining.eligius.st:3334",
"user" : "17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ",
"pass" : "none",
"pool-priority" : "0"
}
]
,
"api-listen" : true,
"api-mcast-port" : "4028",
"api-port" : "4028",
"no-pool-disable" : true,
"submit-stale" : true,
"api-allow" : "W:0/0"
}
{
"pools" : [
{
"url" : "stratum+tcp://stratum.mining.eligius.st:3334",
"user" : "17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ",
"pass" : "none",
"pool-priority" : "0"
}
]
,
"api-listen" : true,
"api-mcast-port" : "4028",
"api-port" : "4028",
"no-pool-disable" : true,
"submit-stale" : true,
"api-allow" : "W:0/0"
}
mittlerweile laufen alle
Re: BFGMiner 3.10.0: modular ASIC+FPGA, GBT+Strtm, RPC, Mac/Lnx/W64, AntU1, DRB, HFA
i use:
ubuntu server
3 x TeckNet® USB 3.0 10 Port Hub
12 x modified antminer (1.1V)
12 x 0.5m usb kable
12 x usb y power adapter kable
only 9 are running i missed the 3rd hub.
i got it.
It look like problems with the usb3 port of my mini pc i use know the usb2 one.
Code:
bfgminer version 3.10.0 - Started: [2014-02-13 19:29:10] - [ 0 days 11:52:32]
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to eu-stratum-lb489kj.btcguild.com diff 16 with stratum as user deagel_BluePie
Block: ...6eceb842 #285742 Diff:2.62G (18.77Ph/s) Started: [07:18:03]
ST:12 F:0 NB:86 AS:1 BW:[137/ 49 B/s] E:67.27 I: 212uBTC/hr BS:310k
9 | 22.35/22.06/26.23Gh/s | A:16129 R:39+2(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.52/ 2.45/ 2.90Gh/s | A: 1764 R: 1+0(.06%) HW:1/.00%
AMU 1: | 2.50/ 2.45/ 2.93Gh/s | A: 1853 R: 5+0(.26%) HW:1/.00%
AMU 2: | 2.42/ 2.45/ 2.91Gh/s | A: 1832 R: 5+0(.27%) HW:1/.00%
AMU 3: | 2.44/ 2.46/ 2.92Gh/s | A: 1807 R: 7+0(.38%) HW:0/none
AMU 4: | 2.49/ 2.45/ 2.92Gh/s | A: 1761 R: 5+0(.28%) HW:1/.00%
AMU 5: | 2.49/ 2.45/ 2.93Gh/s | A: 1783 R: 6+0(.33%) HW:0/none
AMU 6: | 2.53/ 2.46/ 2.94Gh/s | A: 1816 R: 8+2(.44%) HW:0/none
AMU 7: | 2.39/ 2.45/ 2.93Gh/s | A: 1747 R: 2+0(.11%) HW:0/none
AMU 8: | 2.42/ 2.45/ 2.87Gh/s | A: 1772 R: 0+0(none) HW:1/.00%
----------------------------------------------------------------------------------------------------------
[2014-02-14 07:20:52] Accepted 089560b3 AMU 0 pool 1 Diff 29/16
[2014-02-14 07:20:53] Accepted 0ebb84b2 AMU 5 pool 1 Diff 17/16
[2014-02-14 07:20:56] Accepted 03708c1e AMU 1 pool 1 Diff 74/16
[2014-02-14 07:21:01] Accepted 0efe743f AMU 0 pool 1 Diff 17/16
[2014-02-14 07:21:06] Accepted 05aa407e AMU 0 pool 1 Diff 45/16
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to eu-stratum-lb489kj.btcguild.com diff 16 with stratum as user deagel_BluePie
Block: ...6eceb842 #285742 Diff:2.62G (18.77Ph/s) Started: [07:18:03]
ST:12 F:0 NB:86 AS:1 BW:[137/ 49 B/s] E:67.27 I: 212uBTC/hr BS:310k
9 | 22.35/22.06/26.23Gh/s | A:16129 R:39+2(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.52/ 2.45/ 2.90Gh/s | A: 1764 R: 1+0(.06%) HW:1/.00%
AMU 1: | 2.50/ 2.45/ 2.93Gh/s | A: 1853 R: 5+0(.26%) HW:1/.00%
AMU 2: | 2.42/ 2.45/ 2.91Gh/s | A: 1832 R: 5+0(.27%) HW:1/.00%
AMU 3: | 2.44/ 2.46/ 2.92Gh/s | A: 1807 R: 7+0(.38%) HW:0/none
AMU 4: | 2.49/ 2.45/ 2.92Gh/s | A: 1761 R: 5+0(.28%) HW:1/.00%
AMU 5: | 2.49/ 2.45/ 2.93Gh/s | A: 1783 R: 6+0(.33%) HW:0/none
AMU 6: | 2.53/ 2.46/ 2.94Gh/s | A: 1816 R: 8+2(.44%) HW:0/none
AMU 7: | 2.39/ 2.45/ 2.93Gh/s | A: 1747 R: 2+0(.11%) HW:0/none
AMU 8: | 2.42/ 2.45/ 2.87Gh/s | A: 1772 R: 0+0(none) HW:1/.00%
----------------------------------------------------------------------------------------------------------
[2014-02-14 07:20:52] Accepted 089560b3 AMU 0 pool 1 Diff 29/16
[2014-02-14 07:20:53] Accepted 0ebb84b2 AMU 5 pool 1 Diff 17/16
[2014-02-14 07:20:56] Accepted 03708c1e AMU 1 pool 1 Diff 74/16
[2014-02-14 07:21:01] Accepted 0efe743f AMU 0 pool 1 Diff 17/16
[2014-02-14 07:21:06] Accepted 05aa407e AMU 0 pool 1 Diff 45/16
Getting approximately 2.9GH/s out of the Antminer U1's is pretty impressive.
Could you tell us more about what you mean by "modified antminers" please?
Thanks.
Hi,
i did it like written in the antminer userguide.
i changed R1 and R2
DC/DC output 1.1V
R1 3.74K
R2 10K
Hallo Zusammen,
bei mir laufen aktuell 9 von 12 ANT U1 miner mit stabilen 3ghs (2.9ghs), warum 9 naja mir fehlt noch ein hub.
Setup:
Intel Atom mini PC
- 3 x USB3 Hub
- 12 x Antminer die auf 1.1V eingestellt wurden
- 12 x 0,5m USB Kabel
- 12 x USB y power Adapter Kabel
WICHTIG
sehr gute Kühlung
ich habe 2 große Aluminium Kühlkörper genommen und die Ameisen dort direkt daraufgeschraubt und auch jeweils zwei kleine Kühlkörper auf die Oberseite der Ameise geklebt.
Bilder folgen später.
bei mir laufen aktuell 9 von 12 ANT U1 miner mit stabilen 3ghs (2.9ghs), warum 9 naja mir fehlt noch ein hub.
Setup:
Intel Atom mini PC
- 3 x USB3 Hub
- 12 x Antminer die auf 1.1V eingestellt wurden
- 12 x 0,5m USB Kabel
- 12 x USB y power Adapter Kabel
WICHTIG
sehr gute Kühlung
ich habe 2 große Aluminium Kühlkörper genommen und die Ameisen dort direkt daraufgeschraubt und auch jeweils zwei kleine Kühlkörper auf die Oberseite der Ameise geklebt.
Bilder folgen später.
Code:
bfgminer version 3.10.0 - Started: [2014-02-13 19:29:10] - [ 0 days 12:26:47]
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.mining.eligius.st diff 16 with stratum as user 17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ
Block: ...bcd747f5 #285748 Diff:2.62G (18.77Ph/s) Started: [07:49:53]
ST:12 F:0 NB:92 AS:0 BW:[136/ 50 B/s] E:67.50 I: 212uBTC/hr BS:310k
9 | 21.79/22.06/26.26Gh/s | A:16927 R:40+3(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.40/ 2.45/ 2.91Gh/s | A: 1862 R: 1+0(.05%) HW:1/.00%
AMU 1: | 2.46/ 2.45/ 2.94Gh/s | A: 1936 R: 5+0(.25%) HW:1/.00%
AMU 2: | 2.47/ 2.45/ 2.92Gh/s | A: 1908 R: 5+0(.26%) HW:1/.00%
AMU 3: | 2.51/ 2.46/ 2.92Gh/s | A: 1889 R: 7+0(.36%) HW:0/none
AMU 4: | 2.41/ 2.45/ 2.92Gh/s | A: 1844 R: 5+0(.27%) HW:1/.00%
AMU 5: | 2.46/ 2.45/ 2.93Gh/s | A: 1892 R: 6+0(.31%) HW:0/none
AMU 6: | 2.40/ 2.45/ 2.93Gh/s | A: 1903 R: 9+3(.52%) HW:0/none
AMU 7: | 2.43/ 2.45/ 2.93Gh/s | A: 1835 R: 2+0(.11%) HW:0/none
AMU 8: | 2.48/ 2.45/ 2.88Gh/s | A: 1859 R: 0+0(none) HW:1/.00%
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.mining.eligius.st diff 16 with stratum as user 17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ
Block: ...bcd747f5 #285748 Diff:2.62G (18.77Ph/s) Started: [07:49:53]
ST:12 F:0 NB:92 AS:0 BW:[136/ 50 B/s] E:67.50 I: 212uBTC/hr BS:310k
9 | 21.79/22.06/26.26Gh/s | A:16927 R:40+3(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.40/ 2.45/ 2.91Gh/s | A: 1862 R: 1+0(.05%) HW:1/.00%
AMU 1: | 2.46/ 2.45/ 2.94Gh/s | A: 1936 R: 5+0(.25%) HW:1/.00%
AMU 2: | 2.47/ 2.45/ 2.92Gh/s | A: 1908 R: 5+0(.26%) HW:1/.00%
AMU 3: | 2.51/ 2.46/ 2.92Gh/s | A: 1889 R: 7+0(.36%) HW:0/none
AMU 4: | 2.41/ 2.45/ 2.92Gh/s | A: 1844 R: 5+0(.27%) HW:1/.00%
AMU 5: | 2.46/ 2.45/ 2.93Gh/s | A: 1892 R: 6+0(.31%) HW:0/none
AMU 6: | 2.40/ 2.45/ 2.93Gh/s | A: 1903 R: 9+3(.52%) HW:0/none
AMU 7: | 2.43/ 2.45/ 2.93Gh/s | A: 1835 R: 2+0(.11%) HW:0/none
AMU 8: | 2.48/ 2.45/ 2.88Gh/s | A: 1859 R: 0+0(none) HW:1/.00%
Re: Leiterplatten/BGA/SMD/THT Lötarbeiten an (z.B. Anhebung VCore beim Antminer U1)
Hi,
danke noch mal für deine lötarbeiten.
Ich wollte euch nur mitteilen das ich den weg für 3 ghs auf den ant u1 miner gefunden habe.
1.1V wurden eingestellt und sie laufen nun stabiel.
danke noch mal für deine lötarbeiten.
Ich wollte euch nur mitteilen das ich den weg für 3 ghs auf den ant u1 miner gefunden habe.
1.1V wurden eingestellt und sie laufen nun stabiel.
Code:
bfgminer version 3.10.0 - Started: [2014-02-13 19:29:10] - [ 0 days 12:17:15]
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.mining.eligius.st diff 16 with stratum as user 17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ
Block: ...021f6331 #285747 Diff:2.62G (18.77Ph/s) Started: [07:40:28]
ST:12 F:0 NB:91 AS:1 BW:[136/ 50 B/s] E:67.42 I: 212uBTC/hr BS:310k
9 | 22.13/22.06/26.26Gh/s | A:16710 R:39+3(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.45/ 2.45/ 2.91Gh/s | A: 1830 R: 1+0(.05%) HW:1/.00%
AMU 1: | 2.56/ 2.45/ 2.94Gh/s | A: 1917 R: 5+0(.26%) HW:1/.00%
AMU 2: | 2.44/ 2.45/ 2.92Gh/s | A: 1891 R: 5+0(.26%) HW:1/.00%
AMU 3: | 2.52/ 2.46/ 2.92Gh/s | A: 1864 R: 7+0(.37%) HW:0/none
AMU 4: | 2.48/ 2.45/ 2.92Gh/s | A: 1825 R: 5+0(.27%) HW:1/.00%
AMU 5: | 2.48/ 2.45/ 2.93Gh/s | A: 1861 R: 6+0(.32%) HW:0/none
AMU 6: | 2.39/ 2.45/ 2.93Gh/s | A: 1883 R: 8+3(.48%) HW:0/none
AMU 7: | 2.45/ 2.45/ 2.93Gh/s | A: 1808 R: 2+0(.11%) HW:0/none
AMU 8: | 2.51/ 2.45/ 2.87Gh/s | A: 1839 R: 0+0(none) HW:1/.00%
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to stratum.mining.eligius.st diff 16 with stratum as user 17FzphMFv2te1GSiHHP46AY1tWG8KZTYVZ
Block: ...021f6331 #285747 Diff:2.62G (18.77Ph/s) Started: [07:40:28]
ST:12 F:0 NB:91 AS:1 BW:[136/ 50 B/s] E:67.42 I: 212uBTC/hr BS:310k
9 | 22.13/22.06/26.26Gh/s | A:16710 R:39+3(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.45/ 2.45/ 2.91Gh/s | A: 1830 R: 1+0(.05%) HW:1/.00%
AMU 1: | 2.56/ 2.45/ 2.94Gh/s | A: 1917 R: 5+0(.26%) HW:1/.00%
AMU 2: | 2.44/ 2.45/ 2.92Gh/s | A: 1891 R: 5+0(.26%) HW:1/.00%
AMU 3: | 2.52/ 2.46/ 2.92Gh/s | A: 1864 R: 7+0(.37%) HW:0/none
AMU 4: | 2.48/ 2.45/ 2.92Gh/s | A: 1825 R: 5+0(.27%) HW:1/.00%
AMU 5: | 2.48/ 2.45/ 2.93Gh/s | A: 1861 R: 6+0(.32%) HW:0/none
AMU 6: | 2.39/ 2.45/ 2.93Gh/s | A: 1883 R: 8+3(.48%) HW:0/none
AMU 7: | 2.45/ 2.45/ 2.93Gh/s | A: 1808 R: 2+0(.11%) HW:0/none
AMU 8: | 2.51/ 2.45/ 2.87Gh/s | A: 1839 R: 0+0(none) HW:1/.00%
Re: BFGMiner 3.10.0: modular ASIC+FPGA, GBT+Strtm, RPC, Mac/Lnx/W64, AntU1, DRB, HFA
Ok.. suggest breaking this down into smaller pieces.
Just plug in your antminers (which are generally pretty well behaved) and run with a line like:
./bfgminer -S antminer:all --set-device antminer:clock=x0981 -o
And lets see what happens. That speed is pretty much the normal limit pre-mod, let make sure they all show up at that point.
Just plug in your antminers (which are generally pretty well behaved) and run with a line like:
./bfgminer -S antminer:all --set-device antminer:clock=x0981 -o
And lets see what happens. That speed is pretty much the normal limit pre-mod, let make sure they all show up at that point.
hi,
ok more infos:
i use:
ubuntu server
3 x TeckNet® USB 3.0 10 Port Hub
12 x modified antminer (1.1V)
12 x 0.5m usb kable
12 x usb y power adapter kable
only 9 are running i missed the 3rd hub.
i got it.
It look like problems with the usb3 port of my mini pc i use know the usb2 one.
Code:
bfgminer version 3.10.0 - Started: [2014-02-13 19:29:10] - [ 0 days 11:52:32]
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to eu-stratum-lb489kj.btcguild.com diff 16 with stratum as user deagel_BluePie
Block: ...6eceb842 #285742 Diff:2.62G (18.77Ph/s) Started: [07:18:03]
ST:12 F:0 NB:86 AS:1 BW:[137/ 49 B/s] E:67.27 I: 212uBTC/hr BS:310k
9 | 22.35/22.06/26.23Gh/s | A:16129 R:39+2(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.52/ 2.45/ 2.90Gh/s | A: 1764 R: 1+0(.06%) HW:1/.00%
AMU 1: | 2.50/ 2.45/ 2.93Gh/s | A: 1853 R: 5+0(.26%) HW:1/.00%
AMU 2: | 2.42/ 2.45/ 2.91Gh/s | A: 1832 R: 5+0(.27%) HW:1/.00%
AMU 3: | 2.44/ 2.46/ 2.92Gh/s | A: 1807 R: 7+0(.38%) HW:0/none
AMU 4: | 2.49/ 2.45/ 2.92Gh/s | A: 1761 R: 5+0(.28%) HW:1/.00%
AMU 5: | 2.49/ 2.45/ 2.93Gh/s | A: 1783 R: 6+0(.33%) HW:0/none
AMU 6: | 2.53/ 2.46/ 2.94Gh/s | A: 1816 R: 8+2(.44%) HW:0/none
AMU 7: | 2.39/ 2.45/ 2.93Gh/s | A: 1747 R: 2+0(.11%) HW:0/none
AMU 8: | 2.42/ 2.45/ 2.87Gh/s | A: 1772 R: 0+0(none) HW:1/.00%
----------------------------------------------------------------------------------------------------------
[2014-02-14 07:20:52] Accepted 089560b3 AMU 0 pool 1 Diff 29/16
[2014-02-14 07:20:53] Accepted 0ebb84b2 AMU 5 pool 1 Diff 17/16
[2014-02-14 07:20:56] Accepted 03708c1e AMU 1 pool 1 Diff 74/16
[2014-02-14 07:21:01] Accepted 0efe743f AMU 0 pool 1 Diff 17/16
[2014-02-14 07:21:06] Accepted 05aa407e AMU 0 pool 1 Diff 45/16
[M]anage devices [P]ool management [S]ettings [D]isplay options [H]elp [Q]uit
Connected to eu-stratum-lb489kj.btcguild.com diff 16 with stratum as user deagel_BluePie
Block: ...6eceb842 #285742 Diff:2.62G (18.77Ph/s) Started: [07:18:03]
ST:12 F:0 NB:86 AS:1 BW:[137/ 49 B/s] E:67.27 I: 212uBTC/hr BS:310k
9 | 22.35/22.06/26.23Gh/s | A:16129 R:39+2(.24%) HW:5/.00%
----------------------------------------------------------------------------------------------------------
AMU 0: | 2.52/ 2.45/ 2.90Gh/s | A: 1764 R: 1+0(.06%) HW:1/.00%
AMU 1: | 2.50/ 2.45/ 2.93Gh/s | A: 1853 R: 5+0(.26%) HW:1/.00%
AMU 2: | 2.42/ 2.45/ 2.91Gh/s | A: 1832 R: 5+0(.27%) HW:1/.00%
AMU 3: | 2.44/ 2.46/ 2.92Gh/s | A: 1807 R: 7+0(.38%) HW:0/none
AMU 4: | 2.49/ 2.45/ 2.92Gh/s | A: 1761 R: 5+0(.28%) HW:1/.00%
AMU 5: | 2.49/ 2.45/ 2.93Gh/s | A: 1783 R: 6+0(.33%) HW:0/none
AMU 6: | 2.53/ 2.46/ 2.94Gh/s | A: 1816 R: 8+2(.44%) HW:0/none
AMU 7: | 2.39/ 2.45/ 2.93Gh/s | A: 1747 R: 2+0(.11%) HW:0/none
AMU 8: | 2.42/ 2.45/ 2.87Gh/s | A: 1772 R: 0+0(none) HW:1/.00%
----------------------------------------------------------------------------------------------------------
[2014-02-14 07:20:52] Accepted 089560b3 AMU 0 pool 1 Diff 29/16
[2014-02-14 07:20:53] Accepted 0ebb84b2 AMU 5 pool 1 Diff 17/16
[2014-02-14 07:20:56] Accepted 03708c1e AMU 1 pool 1 Diff 74/16
[2014-02-14 07:21:01] Accepted 0efe743f AMU 0 pool 1 Diff 17/16
[2014-02-14 07:21:06] Accepted 05aa407e AMU 0 pool 1 Diff 45/16
Re: BFGMiner 3.10.0: modular ASIC+FPGA, GBT+Strtm, RPC, Mac/Lnx/W64, AntU1, DRB, HFA
Congrats on getting 3.0 ghz stable - make sure you tell us, or the antminer thread, exactly how you did that!
Can you please share your command line?
Can you please share your command line?
hi,
i will do it if my setup is finished.
i have to go know but i can share it tomorrow.
